Master Pursuit 1000w HPS DE Commercial Grow Light

Grower’s Choice proven Double End fixture technology has been enhanced, upgraded, and engineered for even better reliability, performance, efficiency and overall function your garden will appreciate. The new reflector design promotes optimal cross lighting and PPFD. It includes a built-in level for proper mounting and a safety device, lamp catch, has been installed to prevent damage to your garden in the event the lamp becomes dislodged due to improper install or accident. It comes with Grower’s Choice new 1200w Super HPS DE lamp that utilizes your fixtures full energy output, designed to perform in “boost mode”, providing the highest levels of par with the greatest efficiency leading to better harvests.

TECHNICAL INFORMATION

Rated Main Voltage: 240V 277V 347V

Input Current: 5.1A 4.4A 3.8A 3.1A

Input Frequency: 50/60 Hz

Power Factor: >0.98

THD: <10%

Required Lamp Voltage: 200V ~ 280V

Illumination Surface: Indoor 5' X 5' , Green house 8' X 8'

UPGRADED DESIGN AND NEW FEATURES INCLUDE:

The Master Pursuit line utilizes an updated horizontal case to reflector design which accommodates more canopy space. This new case design is reinforced to protect the fixtures internal components and employs heat sinks with greater surface area, translating to better heat distribution, providing further protection, longer fixture life and better efficiency performance.

Clips: Improved ceramic lamp clips keep lamps secure, last longer than plastic clips and redistribute heat better.

Lamp Catch: Innovative safety device prevents damage due to dislodged or improperly installed lamps.

Level: Integrated bubble level provides a visual reference to verify horizontal mounting consistency.

Reflector: Redesigned reflector provides greater heat redistribution, improves cross lighting and PPFD.

Cords: Uses quality hard wired power cords with M25 connectors provide IP65 water resistance.

Dual Ports: Two receptacles for the master controller eliminate the need for split devices or adapters.

AI IGNITION CONTROL:
This revolutionary feature, unique to our products, makes GC Series Digital Ballast the safest and most reliable ballast when used in automated multiple lamp applications. When multiple units are connected to the same mains circuit, our integrated Ignition Control software will completely balance the electrical draw by igniting one lamp at a time to prevent electrical surges and spikes that can overload the mains circuit and trip circuit breaking systems.

SOFT START TECHNOLOGY:
Soft Start Technology prolongs lamp life by stopping current rush to the lamp and preventing lamp overload. When the ballast is started from cold there will be a 3 second fixed delay before ignition. After ignition there will be a series of random 0-2 second delays before full brightness is reached after approximately 3-5 minutes.

RE-STRIKE OF HOT LAMP AFTER MAINS FAILURE:
The GC Series Digital Ballast uses a timed re-strike system that prevents the ballast from re-striking a hot lamp after a power failure. If a hot lamp is detected, the re-strike will be delayed for 60 second intervals until the lamp has cooled sufficiently to be re-ignited.

LAMP COMPATIBILITY:
The GC Series Digital Ballast is suitable for use with all good quality HPS, Metal Halide and Ceramic Metal Halide lamps. For a guaranteed perfect match and the best results we recommend Grower’s Choice horticultural lamps. Grower’s Choice lamps are optimized for use with high efficiency electronic ballasts with adjustable output.

HIGH ENERGY EFFICIENCY:
Soft Start The GC Series Digital Ballast is up to 30% more efficient than standard magnetic ballast producing more lumens of light per watt of consumed energy. Efficiency does not diminish and is maintained for the entire life of the unit.

AUTOMATIC FREQUENCY ADJUSTMENT:
The GC Series Digital Ballast automatically adjusts its output frequency to maintain a constant output regardless of input power fluctuations and ageing lamps. This also prevents 'lamp flicker'.

FULL CIRCUIT PROTECTION:
The GC Series Digital Ballast uses a sophisticated software controlled circuit breaking system that is not seen in other manufacturer's ballasts. The system protects against a series of faults including: Open Circuit Protection, Short Circuit Protection, Over Voltage Protection, Under Voltage Protection and Over Temperature Protection.

RUNNING TEMPERATURE:
The GC Series Digital Ballasts' unique case design acts as a superior heat sink making the ballast extremely cool running without the need for internal fans.

RF SHIELDING:
The GC Series Digital Ballast has superior RF Shielding with Total Harmonic Distortion (THD) of less than 10% meaning it will not interfere with television or radio equipment.

SILENT OPERATION:
This fixture doesn't have noisy internal fans and is completely silent in operation.

CHOOSE BETWEEN LAMPS:

2K 1200W Double Ended Super HPS

• Only 1200 watt rated HPS lamp in the industry
• 5 times better degeneration rate compares to other premium 1000W lamps power at 1150-1200W
• 5% more efficient than other premium 1000W lamps power at 1150-1200W
• Exceeds 2500 umol/s
• Best Par Maintenance
• Constructed with Philips inner arc tube

2K 1000W Double Ended HPS

• Outputs UV spectra for enhanced resin production
• 5% degradation rate at 10,000 hours
• High quality quartz glass for consistent spectral output and PAR production
• Rated for 2,100 umol

4K 1000W Double Ended MH

• Outputs UV spectra for enhanced resin production
• 5% degradation rate at 10,000 hours
• High quality quartz glass for consistent spectral output and PAR production
• Designed to prolong bulb life and preserve light quality

6K 1000W Double Ended MH

• Mimics spring time light, promotes short inter-nodal spacing
• High quality quartz glass for consistent spectral output and PAR production
• Great for commercial applications where a large vegetative footprint is desired
